SUV-TRUCK-VAN  YEAR  BOLT PATTERN  STUD SIZE  HUB DIAMETER
ACADIA 08 – 16′ 6×132 14×1.5 74.5
ACADIA 2017 6×120 14×1.5 66.9
C-1500 71′ – 87′ 5×5 / 5×127 1/2″ 78.1
C-1500 88′ – 98′ 5×5 / 5×127 14×1.5 78.1
C-2500 (6-LUG) 88′ – 00′ 6×5.5 / 6×139.7 14×1.5 78.1
C-2500 (8-LUG) 88′ – 00′ 8×6.5 / 8×165.1 14×1.5 116.7
C-3500 88′ – 00′ 8×6.5 / 8×165.1 14×1.5 116.7
CABALLERO 78′ – 87′ 5×4.75 / 5×120.7 12×1.5 70.3
CANYON 04′ – 12′ 6×5.5 / 139.7 12×1.5 100.5
CANYON 15′ – 18′ 6×120 14×1.5 66.9
CENSOR 08′ – 14′ 6×5.5 / 6×139.7 12×1.5 108
ENVOY 03′ – 09′ 6×5 / 6×127 12×1.5 78.1
JIMMY 95′ – 02′ 5×4.75 / 5×120.7 12×1.5 70.3
K-1500 88′ – 98′ 6×5.5 / 139.7 14×1.5 78.1
K-2500 (6-LUG) 88′ – 00′ 6×5.5 / 139.7 14×1.5 78.1
K-2500 (8-LUG) 88′ – 00′ 8×6.5 / 8×165.1 14×1.5 116.7
K-3500 88′ – 00′ 8×6.5 / 8×165.1 14×1.5 116.7
SAFARI 95′ – 02′ 5×5 / 5×127 1/2″ 78.1
SAFARI 03′ – 05′ 6×5.5 / 6×139.7 14×1.5 78.1
SAVANA VAN 1500 03′ – 14′ 6×5.5 / 6×139.7 14×1.5 78.1
SAVANA VAN 2500 97′ – 17′ 8×6.5 / 8×165.1 14×1.5 116.7
SAVANA VAN 3500 97′ – 17′ 8×6.5 / 8×165.1 14×1.5 116.7
SIERRA 1500 99′ – 18′ 6×5.5 / 6×139.7 14×1.5 78.1
SIERRA 2500 HD 01′ – 10′ 8×6.5 / 8×165.1 14×1.5 116.7
SIERRA 2500 HD 11′ – 18′ 8×180 14×1.5 124.1
SIERRA 3500 99′ – 10′ 8×6.5 / 8×139.7 14×1.5 116.7
SIERRA 3500 11′ – 18′ 8×180 14×1.5 124.1
SIERRA DUALLY 3500 82′ –  10′ 8×6.5 / 8×165.1 14×1.5 116.7
SIERRA DUALLY 3500 11′ – 18′ 8×210 14×1.5 154.2
SONOMA 95′ – 04′ 5×4.75 / 5×120.7 12×1.5 70.3
SPRINT 71′ – 77′ 5×4.75 / 5×120.7 7/16″ 70.3
SYCLONE 91′ – 93′ 5×4.75 / 5×120.7 12×1.5 70.3
TERRAIN 10′ – 17′ 5×120 14×1.5 66.9
YUKON 2WD 92′ – 99′ 5×5 / 5×127 14×1.5 78.1
YUKON 4WD 92′ – 99′ 6×5.5 / 6×139.7 14×1.5 78.1
YUKON 1500 00′ – 18′ 6×5.5 / 6×139.7 14×1.5 78.1
YUKON 2500 00′ – 13′ 8×6.5 / 8×165.1 14×1.5 116.7
