BMW Wheel Spacers

BMW wheel spacers offered here are organized by year and model. The #1 Recommendation for any model BMW is a hub centric wheel spacer. Click the link on your model BMW to view all spacers available for that year make and model. Some years and models could be using different sized Lug Bolts.  Check vehicle before placing order.

BMW Model	YEAR	BOLT PATTERN	STUD SIZE	HUB DIAMETER
1 Series	08′ – 11′	5×120	12×1.5B	72.56
2 Series	14′ – 17′	5×120	12×1.5B	72.56
3 Series	92′ – 12′	5×120	12×1.5B	72.56
328, Hybrid (12×1.5 Bolts) 328, Hybrid (14×1.25 Bolts)	13′ – 16′	5×120	12×1.5B 14×1.25B	72.56
3 Series	17′ – 19′	5×120	14×1.25B	72.56
330i, 330i XDrive	19′ – 20′	5×112	14×1.25B	66.56
4 Series	14′ – 19′	5×120	14×1.25B	72.56
525, 528, 530, 540	89′ – 96′	5×120	12×1.5B	72.56
525, 528, 530, 540	97′ – 03′	5×120	12×1.5B	74.1
525, 530, 545	04′ – 05′	5×120	12×1.5B	72.56
525, 528, 550, 550(GT), 5-XDrive	06′ – 10′	5×120	12×1.5B	72.56
528, 535, 5 X-Drive	13′ – 18′	5×120	14×1.25B	72.56
528, 535, 550 Sedan (12×1.5 Bolts) 528, 535, 550 Sedan (14×1.25 Bolts)	11′ – 12′	5×120	12×1.5B 14×1.25B	72.56
5 Hybrid	13′ – 16′	5×120	14×1.25B	72.56
530, 540(D) + XDrive	17′ – 20′	5×112	14×1.25B	66.56
535 GT + XDrive	13′ – 17′	5×120	14×1.25B	72.56
645, 650	04′ – 10′	5×120	12×1.5B	72.56
6 Series	12′ – 19′	5×120	14×1.25B	72.56
740, 750	89′ – 01′	5×120	12×1.5B	72.56
745, 750, 760 (12×1.5 Bolts) 745, 750, 760 (14×1.25 Bolts)	02′ – 08′	5×120	12×1.5B 14×1.25B	72.56
740, 750, 760	09′ – 15′	5×120	14×1.25B	72.56
740, 750	16′ – 20′	5×112	14×1.25B	66.56
8 Series	92′ – 97′	5×120	12×1.5B	72.56
8 Series	2020	5×112	14×1.25B	66.56
Alpina B6 XDrive Gran Coupe	15′ – 17′	5×120	14×1.25B	72.56
I8	14′ – 20′	5×112	14×1.25B	66.56
M2	14′ – 19′	5×120	14×1.25B	72.56
M235	14′ – 16′	5×120	14×1.25B	72.56
M240	17′ – 19′	5×120	14×1.25B	72.56
M3	95′ – 13′	5×120	12×1.5B	72.56
M3	15′ – 18′	5×120	14×1.25B	72.56
M4	15′ – 19′	5×120	14×1.25B	72.56
M5	01′ – 03′	5×120	12×1.5B	74.1
M5	06′ – 10′	5×120	12×1.5B	72.56
M5	13′ – 16′	5×120	14×1.25B	72.56
M5	18′ – 20′	5×112	14×1.25B	66.56
M6	06′ – 10′	5×120	12×1.5B	72.56
M6	13′ – 19′	5×120	14×1.25B	72.56
M760	17′ – 20′	5×112	14×1.25B	66.56
M850	19′ – 20′	5×112	14×1.25B	66.56
Z3	96′ – 02′	5×120	12×1.25B	72.56
Z4	03′ – 16′	5×120	12×1.25B	72.56
Z4	2020	5×112	14×1.25B	66.56



BMW Wheel Spacers (SUVs)

SUV
X1	13′ – 15′	5×120	12×1.5B	72.56
X1	17′ – 20′	5×112	14×1.25B	66.56
X2	18′ – 20′	5×112	14×1.25B	66.56
X3	04′ – 10′	5×120	14×1.5B	72.56
X3	11′ – 18′	5×120	14×1.25B	72.56
X3	18′ – 20′	5×112	14×1.25B	66.56
X4	15′ – 18′	5×120	14×1.25B	72.56
X4	19′ – 20′	5×112	14×1.25B	66.56
X5	00′ – 01′	5×120	14×1.5B	72.56
X5 (14×1.5 Bolts) X5 (14×1.25 Bolts)	02′ – 06′	5×120	14×1.5B 14×1.25B	72.56
X5	07′ – 17′	5×120	14×1.25B	74.1
X5	19′ – 20′	5×112	14×1.25B	66.56
X6 (Front) X6 (Rear)	08′ – 19′	5×120	14×1.25B	F-74.1 R-72.56
X6	2020	5×112	14×1.25B	66.56
X7	19′ – 20′	5×112	14×1.25B	66.56
