VEHICLE  YEAR  BOLT PATTERN  STUD SIZE HUB DIAMETER
C30 08′ – 13′ 5×4.25 / 5×108 12×1.5 63.4
C70 01′ – 04′ 5×4.25 / 5×108 12×1.75B 65.1
C70 2005 5×4.25 / 5×108 14×1.5B 63.4
C70 06′ – 13′ 5×4.25 / 5×108 12×1.5 63.4
S40 (4-LUG) 03′ – 04′ 4×4.5 / 4×114.3 12×1.5 67.1
S40 (5-LUG) 04′ – 11′ 5×4.25 / 5×108 12×1.5 63.4
S60 12′ – 17′ 5×4.25 / 5×108 14×1.5B 63.4
S80 99′ – 05′ 5×4.25 / 5×108 14×1.5B 65.1
S80 06′ – 16′ 5×4.25 / 5×108 14×1.5B 63.4
S90 2017 5×4.25 / 5×108 14×1.5B 63.4
V50 05′ – 11′ 5×4.25 / 5×108 12×1.5 63.4
V60 15′ – 17′ 5×4.25 / 5×108 14×1.5B 63.4
V70 00′ – 07′ 5×4.25 / 5×108 14×1.5B 65.1
V70 08′ – 10′ 5×4.25 / 5×108 14×1.5B 63.4
XR70 01′ – 05′ 5×4.25 / 5×108 14×1.5B 63.4
SUV
XC60 10′ – 17′ 5×4.25 / 5×108 14×1.5B 63.4
XC70 01′ – 15′ 5×4.25 / 5×108 14×1.5B 63.4
XC90 04′ – 14′ 5×4.25 / 5×108 14×1.5B 67.1
XC90 16′ – 17′ 5×4.25 / 5×108 14×1.5B 63.4
