SUV-TRUCK-VAN  YEAR  BOLT PATTERN  STUD SIZE HUB DIAMETER
E-SERIES E-150 92′ – 06′ 5×5.5 / 5×139.7 1/2″ 87
E-SERIES E-150 07′ – 14′ 8×6.5 / 8×165.1 9/16″ OR 1/2″ 124.9
E-SERIES E-250 92′ – 14′ 8×6.5 / 8×165.1 9/16″ OR 1/2″ 124.9
E-SERIES E-350 92′ – 14′ 8×6.5 / 8×165.1 9/16″ OR 1/2″ 124.9
EDGE 07′ – 10′ 5×4.5 / 5×114.3 1/2″ 70.5
EDGE 11′ – 14′ 5×4.5 / 5×114.3 1/2″ 63.4
EDGE 15′ – 17′ 5×4.25 / 5×108 14×1.5 63.4
ESCAPE 01′ – 12′ 5×4.5 / 5×114.3 12×1.5 67.1
ESCAPE 13′ – 17′ 5×4.25 / 5×108 12×1.5 63.4
EXCURSION 00′ – 02′ 8×170 14×2.0 124.9
EXCURSION 03′ – 05′ 5×135 14×1.5 124.9
EXPEDITION 97′ – 99′ 5×135 12×1.75 87
EXPEDITION 00′ – 02′ 5×135 14×2.0 87
EXPEDITION 03′ – 14′ 6×135 14×2.0 87
EXPEDITION 15′ – 17′ 6×135 14×1.5 87
EXPLORER 91′ – 10′ 5×4.5 / 5×114.3 1/2″ 70.5
EXPLORER 11′ – 17′ 5×4.5 / 5×114.3 1/2″ 63.4
F-150 92′ – 96′ 5×5.5 / 5×139.7 1/2″ 87
F-150 97′ – 03′ 5×135 12×1.75 OR 14×2.0 87
F-150 04′ – 14′ 6×135 14×2.0 87
F-150 15′ -18′ 6×135 14×1.5 87
F-150 SVT LIGHTNING 99′ -04′ 5×135 14×2.0 87
F-150 RAPTOR 10′ -14′ 6×135 14×2.0 87
F-150 RAPTOR 15′ – 17′ 6×135 14×1.5 87
F-150 HEAVY DUTY (7-LUG) 04′ – 13′ 7×150 14×2.0 87
F-250 81′ – 97′ 8×6.5 / 8×165.1 9/16″ OR 1/2″ 124.9
F-250 99′ – 16′ 8×6.7 / 8×170 14×1.5 OR 14×2.0 124.9
F-250 17′ – 18′ 8×6.7 / 8×170 14×1.5 124.9
F-350 81′ – 97′ 8×6.5 / 8×165.1 9/16″ OR 1/2″ 124.9
F-350 99′ – 16′ 8×6.7 / 8×170 14×1.5 OR 14×2.0 124.9
F-350 17′ – 18′ 8×6.7 / 8×170 14×1.5 124.9
F-350 DUALLY 88′ – 98′ 8×6.5 / 8×165.1 9/16″ 124.9
F-350 DUALLY 99′ – 04′ 8×6.7 / 8×170 14×1.5 OR 14×2.0 124.9
F-350 DUALLY 05′ – 18′ 8×7.9 / 8×200 14×1.5 142
FLEX 09′ – 17′ 5×4.5 / 5×114.3 1/2″ 63.4
FREESTAR 04′ – 05′ 5×4.25 / 5×108 1/2″ 63.4
FREESTAR 06′ – 07′ 5×4.5 / 5×114.3 1/2″ 63.4
FREESTYLE 05′ – 07′ 5×4.5 / 5×114.3 1/2″ 63.4
RANGER 91′ – 11′ 5×4.5 / 5×114.3 1/2″ 70.5
TAURUS X 08′ – 09′ 5×4.5 / 5×114.3 1/2″ 63.4
TRANSIT 150 – 250 – 350 15′ – 17′ 5×160 14×1.5 65.1
TRANSIT CONNECT 10′ – 17′ 5×4.25 / 5×108 12×1.5 63.4
WINDSTAR 95′ – 03′ 5×4.25 / 5×108 12×1.5 63.4



CAR
C-MAX 13′ – 17′ 5×4.25 / 5×108 12×1.5 63.4
CONTOUR 95′ – 00′ 4×4.25 / 4×108 12×1.5 63.4
CRESTLINE 52′ – 54′ 5×4.5 / 5×114.3 1/2″ 70.5
CROWN VICTORIA 92′ – 11′ 5×4.5 / 5×114.3 1/2″ 70.5
ESCORT 81′ – 90′ 4×4.25 / 4×108 12×1.5 63.4
FAIRLANE 55′ – 67′ 5×4.5 / 5×114.3 1/2″ 70.5
FALCON 60′ – 65′ 4×4.5 / 4×114.3 1/2″ 62
FIESTA 11′ – 17′ 4×4.25 / 4×108 12×1.5 63.4
FIVE HUNDRED (500) 05′ – 07′ 5×4.5 / 5×114.3 1/2″ 63.4
FOCUS 03′ – 11′ 4×4.25 / 4×108 12×1.5 63.4
FOCUS 12′ – 17′ 5×4.25 / 5×108 12×1.5 63.4
FUSION 06′ – 12′ 5×4.5 / 5×114.3 12×1.5 67.1
FUSION 13′ – 17′ 5×4.25 / 5×108 12×1.5 63.4
GALAXIE 60′ – 74′ 5×4.5 / 5×114.3 1/2″ 70.5
MAINLINE 52′ – 54′ 5×4.5 / 5×114.3 1/2″ 70.5
MUSTANG (4-LUG) 64′ – 68′ 4×4.5 / 4×114.3 1/2″ 62
MUSTANG (5-LUG) 64′ – 73′ 5×4.5 / 5×114.3 1/2″ 70.5
MUSTANG 74′ – 93′ 4×4.25 / 4×108 1/2″ 63.4
MUSTANG 94′ – 14′ 5×4.5 / 5×114.3 1/2″ 70.5
MUSTANG 15′ – 17′ 5×4.5 / 5×114.3 14×1.5 70.5
PROBE 93′ – 97′ 5×4.5 / 5×114.3 12×1.5 67.1
TAURUS 86′ – 07′ 5×4.25 / 5×108 12×1.5 63.4
TAURUS 08′ – 17′ 5×4.5 / 5×114.3 1/2″ 70.5
THUNDERBIRD 58′ – 71′ 5×4.5 / 5×114.3 1/2″ 70.5
THUNDERBIRD 83′ – 88′ 5×4.25 / 5×108 1/2″ 63.4
THUNDERBIRD 89′ – 97′ 5×4.25 / 5×108 12×1.5 63.4
THUNDERBIRD 02′ – 06′ 5×4.25 / 5×108 12×1.5 63.4
VX3 97′ – 02′ 4×4.25 / 4×108 12×1.5 54.1
ZX2 98′ – 03′ 4×100 12×1.5 54.1
