VEHICLE  YEAR  BOLT PATTERN  STUD SIZE HUB DIAMETER
3000 GT 91′ – 98′ 5×4.5 / 5×114.3 12×1.5 67.1
DIAMANTE 93′ – 04′ 5×4.5 / 5×114.3 12×1.5 67.1
ECLIPSE  95′ – 12′ 5×4.5 / 5×114.3 12×1.5 67.1
GALANT 93′ – 12′ 5×4.5 / 5×114.3 12×1.5 67.1
I-MIEV 12′ – 14′ 4×100 12×1.5 56.1
LANCER 02′ – 17′ 5×4.5 / 5×114.3 12×1.5 67.1
LANCER ES 02′ – 05′ 4×100 12×1.5 56.1
LANCER OZ RALLY 02′ – 06′ 4×4.5 / 4×114.3 12×1.5 56.1
MIRAGE 91′ – 17′ 4×100 12×1.5 56.1
SUV-TRUCK-VAN
ENDEAVOR 04′ – 11′ 5×4.5 / 5×114.3 12×1.5 67.1
MONTERO 01′ – 06′ 6×5.5 / 6×139.7 12×1.5 67.1
MONTERO SPORT 97′ – 04′ 6×5.5 / 6×139.7 12×1.5 108
OUTLANDER 03′ – 17′ 5×4.5 / 5×114.3 12×1.5 67.1
RAIDER 06′ – 09′ 5×5.5 / 5×139.7 9/16″ 77.8
