SUV-TRUCK-VAN YEAR BOLT PATTERN STUD SIZE HUB DIAMETER
ASTRO VAN 85′ – 01′ 5×5 / 5×127 1/2″ 78.1
ASTRO VAN 02′ – 05′ 6×5.5 / 6×139.7 14×1.5 78.1
AVALANCHE 1500 02′ – 13′ 6×5.5 / 6×139.7 14×1.5 78.1
AVALANCHE 2500 02′ – 07′ 8×6.5 / 8×165.1 14×1.5 116.7
BLAZER S-10 83′ – 05′ 5×4.75 / 5×120.7 12×1.5 70.3
C-1500 PICKUP 2WD 71′ – 87′ 5×5 / 5×127 1/2″ 78.1
C-1500 PICKUP 2WD 88′ – 98′ 5×5 / 5×127 14×1.5 78.1
C-2500 PICKUP 2WD 88′ – 00′ 6×5.5 / 139.7 14×1.5 78.1
C-2500 PICKUP 2WD HD (8-LUG) 88′ – 00′ 8×6.5 / 8×165.1 14×1.5 116.7
C-3500 2WD 88′ – 00′ 8×6.5 / 8×165.1 14×1.5 116.7
CITY EXPRESS 15′ – 17′ 5×4.5/5×114.3 12×1.25 66.1
COLORADO 04′ – 12′ 6×5.5 / 139.7 12×1.5 100.5
COLORADO 15′ – 18′ 6X120 14X1.5 66.9
EL CAMINO 64′ – 81′ 5×4.75 / 5×120.7 7/16″ 70.3
EL CAMINO 82′ – 87′ 5×4.75 / 5×120.7 12×1.5 70.3
EQUINOX 05′ – 09′ 5×115 12×1.5 70.3
EQUINOX 10′ – 17′ 5×120 14X1.5 66.9
EXPRESS VAN 1500 97′ – 02′ 5×5 / 5×127 14X1.5 78.1
EXPRESS VAN 1500 03′ – 14′ 6×5.5 / 139.7 14X1.5 78.1
EXPRESS VAN 2500 97′ – 17′ 6×5.5 / 139.7 14X1.5 78.1
EXPRESS VAN 3500 97′ – 17′ 6×5.5 / 139.7 14X1.5 78.1
K-1500 88′ – 98′ 6×5.5 / 139.7 14X1.5 78.1
K-2500 (6-LUG) 88′ – 98′ 6×5.5 / 139.7 14X1.5 78.1
K-2500 (8-LUG) 88′ – 98′ 8×6.5 / 8×165.1 14X1.5 116.7
K-3500 88′ – 98′ 8×6.5 / 8×165.1 14X1.5 116.7
S-10 02′ – 04′ 5×4.75 / 5×120.7 12×1.5 70.3
SILVERADO 1500 99′ – 18′ 6X5.5 / 6X139.7 14X1.5 78.1
SILVERADO 2500 99′ – 10′ 8×6.5 / 8×165.1 14X1.5 116.7
SILVERADO 2500 11′ – 18′ 8X180 14X1.5 124.1
SILVERADO 3500 99′ – 10′ 8×6.5 / 8×165.1 14X1.5 116.7
SILVERADO 3500 11′ -18′ 8X180 14X1.5 124.1
SILVERADO DUALLY 3500 00′ -10′ 8×6.5 / 8×165.1 14X1.5 116.7
SILVERADO DUALLY 3500 11′ – 18′ 8X210 14X1.5 154.2
SSR 04′ – 06′ 6X5 / 6X127 12×1.5 78.1
SUBURBAN 1500 88′ – 99′ 5×5 / 5×127 14X1.5 78.1
SUBURBAN 1500 00′ – 18′ 6X5.5 / 6X139.7 14X1.5 78.1
SUBURBAN 2500 89′ – 13′ 8×6.5 / 8×165.1 14X1.5 116.7
TAHOE 2WD 95′ – 99′ 5×5 / 5×127 14X.15 78.1
TAHOE 4WD 95′ – 18′ 6X5.5 / 6X139.7 14X1.5 78.1
TRACKER 92′ – 04′ 5X5.5 / 5X139.7 12×1.25 108
TRAILBLAZER 02′ – 09′ 6X5 / 6X127 12×1.5 78.1
TRAVERSE 09′ – 17′ 6X132 14X1.5 74.5
TRAX 15′ – 17′ 5X105 12×1.5 56.5
TYPHOON 91′ – 93′ 5×4.75 / 5×120.7 12×1.5 70.3
UPLANDER 2005 5×115 12×1.5 70.3
UPLANDER 06′ – 09′ 6X115 12×1.5 70.3
VENTURE 97′ – 05′ 5×115 12×1.5 70.3



CAR
AVEO 04′ – 11′ 4×100 12×1.5 56.6
BEL AIR 55′ – 77′ 5×4.75 / 5×120.7 7/16″ 70.3
BERETTA 87′ – 96′ 5×100 12×1.5 57.1
BISCAYNE 65′ – 67′ 5×4.75 / 5×120.7 7/16″ 70.3
CAMARO 67′ – 81′ 5×4.75 / 5×120.7 7/16″ 70.3
CAMARO 82′ – 02′ 5×4.75 / 5×120.7 12×1.5 70.3
CAMARO 10′ – 18′ 5×120 14×1.5 66.9
CAPRICE 80′ – 89′ 5×4.75 / 5×120.7 7/16″ 70.3
CAPRICE 91′ – 97′ 5×5 / 5×127 12×1.5 78.1
CAVALIER 91′ – 04′ 5×100 12×1.5 57.1
CELEBRITY 80′ – 89′ 5×100 12×1.5 57.1
CELEBRITY EUROSPORT 82′ – 89′ 5×115 12×1.5 70.3
CHEVELLE 64′ – 72′ 5×4.75 / 5×120.7 7/16″ 70.3
CHEVETTE 75′ – 86′ 4×100 12×1.5 57.1
CITATION 80′ – 86′ 5×100 12×1.5 57.1
COBALT (4-Lug) 05′ – 10′ 4×100 12×1.5 57.1
COBALT (5-Lug) 05′ – 10′ 5×110 12×1.5 65.1
CORSICA 87′ – 96′ 5×100 12×1.5 57.1
CORVETTE 68′ – 82′ 5×4.75 / 5×120.7 7/16″ 70.3
CORVETTE 84′ – 18′ 5×4.75 / 5×120.7 12×1.5 70.3
CRUISE 11′ – 17′ 5×105 12×1.5 56.5
CRUISE (Turbo Diesal) 14′ – 15′ 5×115 12×1.5 56.5
GEO PRISM 93′ – 03′ 4×100 12×1.5 54.1
HHR 06′ – 11′ 5×110 12×1.5 65.1
IMPALA 58′ – 70′ 5×4.75 / 5×120.7 7/16″ 70.3
IMPALA 94′ – 96′ 5×5 / 5×127 12×1.5 78.3
IMPALA 00′  – 16′ 5×115 12×1.5 70.3
IMPALA LS, LT, LTZ, PREMIER 14′ – 18′ 5×120 14×1.5 70.3
LUMINA 90′ – 01′ 5×115 12×1.5 70.3
MALIBU 97′ – 03′ 5×115 12×1.5 70.3
MALIBU 04′ – 12′ 5×110 12×1.5 65.1
MALIBU 13′ – 17′ 5×120 14×1.5 66.9
MALIBU LS, LT, LTZ, PREMIER 16′ – 17′ 5×115 12×1.5 70.3
MONTE CARLO 95′ – 07′ 5×115 12×1.5 70.3
NOVA – CHEVY II 62′ – 65′ 5×4.75 / 5×120.7 7/16″ 70.3
NOVA 68′ – 74′ 5×4.75 / 5×120.7 7/16″ 70.3
SONIC 12′ – 17′ 5×105 12×1.5 56.6
SPARK 13′ – 17′ 4×100 12×1.5 56.6
SPRINT 88′ – 89′ 4×4.5 / 4×114.3 10×1.25 59.6
SS 14′ – 16′ 5×120 14X1.5 66.9
VENTURE 97′ – 05′ 5×115 12×1.5 70.3
VOLT 11′ – 15′ 5×115 12×1.5 70.3
VOLT 16′ – 17′ 5×105 12×1.5 56.5
